FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
38 Error Check Method and Error Code List
38.1 States and Colors of LEDs PLC Operation Status
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
38.1.1 POWER (POW) LED [lit, flickering or unlit] [FX3G/FX3U/FX3GC/FX3UC]
38.1.2 RUN LED [lit or unlit] [FX3G/FX3U/FX3GC/FX3UC]
38.1.3 BATT (BAT) LED [lit or unlit] [FX3U/FX3UC]
38.1.4 ALM LED [lit or unlit] [FX3G/FX3GC]
This LED is valid when the optional battery is installed and the battery mode is selected using a parameter.
LED status PLC status Action
Lit
The voltage is correctly supplied to the power
terminal.
The power supply is normal.
Flickering
One of the following has occurred:
• The voltage or current is incorrectly supplied
to the power terminal.
• The wiring is incorrect.
• There is fault inside the PLC.
• Check the power supply voltage.
• Disconnect cables except the power cable, turn the PLC power
ON again, and verify that the status is changed.
If the status is not improved, consult a Mitsubishi Electric
representative.
Unlit
One of the following has occurred:
• The power is OFF.
• The voltage is incorrectly supplied to the
power terminal.
• There is a break in the power cable.
When the power is not OFF, check the power supply and power
line route.
When the power is correctly supplied, consult a Mitsubishi Electric
representative.
LED status PLC status Action
Lit Sequence program is executing. The PLC operation status is indicated.
This LED is not lit depending on the ERROR (ERR) LED status.
(Refer to Subsection 38.1.4.)
Unlit Sequence program is stopped.
LED status PLC status Action
Lit The battery voltage is low.
Replace the battery as soon as possible.
(Refer to FX3U/FX3UC Hardware edition.)
Unlit
The battery voltage exceeds the value set in
D8006.
The battery is normal.
LED status PLC status Action
Lit The battery voltage is low.
Replace the battery as soon as possible.
(Refer to FX3G/FX3GC Hardware edition.)
Unlit
The battery voltage exceeds the value set in
D8006.
The battery is normal.

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
