2.6 Program Memory and Devices
2.6.1 Memory structure
1. In FX3U/FX3UC PLCs
FX3U/FX3UC PLCs are equipped with the RAM memory as standard.
By mounting a memory cassette, the memory type can be changed.
1) When using the built-in memory (without attached memory cassette)
CPU System ROM
Built-in program memory
(RAM)
Parameter
File register (D)
Comment
Sequence program
Special setting
Memory cassette
(Flash memory)
Not attached
Built-in device memory (RAM)
[Bit device memory]
• Data register (D)
• Timer present value register (T)
• Counter present value register (C)
• Index register (V, Z)
Contact image memory
• Input relay (X) • Output relay (Y)
• Auxiliary relay (M) • State relay (S)
Timer contact and time counting coil
Counter contact, counting coil, and reset coil
• Extension register (R)
[Data memory]
Symbolic information
