FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
35 SFC Program and Step Ladder
35.1 SFC Program
35.1.9 Program of branch/recombination state relays
Selective branch
After making a branch, create a transfer condition.
Selective recombination
After creating a transfer condition, recombine.
Parallel branch
After creating a transfer condition, make a branch.
Parallel recombination
After recombining, create a transfer condition.
21
20
X000
1
TRAN
31
X001
11
TRAN
41
X002
21
TRAN
50
29
X010
10
TRAN
20
X011
39
TRAN
30
X012
49
TRAN
21
20
X000
1
TRAN
31 41
50
29
X010
10
TRAN
39 49

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
