35 SFC Program and Step Ladder

35.1 SFC Program

*1. Output coils can be used again in different state relays.

SET Y31

State relay number

Y030

Y032

Y030

When X001

turns ON

S32 is activated,

and S31 is

automatically

reset.

ctivated

Transfer

condition

X001

Transfer condition

number

Internal circuit

TRAN

X002

TRAN

SET Y31

Y030

Y032

Y030

Activated

X001

TRAN

X002

TRAN

Y31 programmed

in the SET instruction

remains ON even

if S31 turns OFF.
