824
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
37 Operation of Special Devices (M8000 -, D8000 -)
37.1 Special Device List (M8000 -, D8000 -)
Counter Up/down Counter Counting Direction (Refer to Section 4.6 for details.)
M 8200 C200
When M8 is ON, the
corresponding C is changed to
down mode.
ON: Down count operation
OFF: Up count operation
3 3 3 3 ––33 3 3
M 8201 C201
3 3 3 3 ––33 3 3
M 8202 C202
3 3 3 3 ––33 3 3
M 8203 C203
3 3 3 3 ––33 3 3
M 8204 C204
3 3 3 3 ––33 3 3
M 8205 C205
3 3 3 3 ––33 3 3
M 8206 C206
3 3 3 3 ––33 3 3
M 8207 C207
3 3 3 3 ––33 3 3
M 8208 C208
3 3 3 3 ––33 3 3
M 8209 C209
3 3 3 3 ––33 3 3
M 8210 C210
3 3 3 3 ––33 3 3
M 8211 C211
3 3 3 3 ––33 3 3
M 8212 C212
3 3 3 3 ––33 3 3
M 8213 C213
3 3 3 3 ––33 3 3
M 8214 C214
3 3 3 3 ––33 3 3
M 8215 C215
3 3 3 3 ––33 3 3
M 8216 C216
3 3 3 3 ––33 3 3
M 8217 C217
3 3 3 3 ––33 3 3
M 8218 C218
3 3 3 3 ––33 3 3
M 8219 C219
3 3 3 3 ––33 3 3
M 8220 C220
3 3 3 3 ––33 3 3
M 8221 C221
3 3 3 3 ––33 3 3
M 8222 C222
3 3 3 3 ––33 3 3
M 8223 C223
3 3 3 3 ––33 3 3
M 8224 C224
3 3 3 3 ––33 3 3
M 8225 C225
3 3 3 3 ––33 3 3
M 8226 C226
3 3 3 3 ––33 3 3
M 8227 C227
3 3 3 3 ––33 3 3
M 8228 C228
3 3 3 3 ––33 3 3
M 8229 C229
3 3 3 3 ––33 3 3
M 8230 C230
3 3 3 3 ––33 3 3
M 8231 C231
3 3 3 3 ––33 3 3
M 8232 C232
3 3 3 3 ––33 3 3
M 8233 C233
3 3 3 3 ––33 3 3
M 8234 C234
3 3 3 3 ––33 3 3
Number and name Operation and function
Applicable model
FX
3G
FX
3GC FX3U
FX
3UC
Correspond-
ing special
device
FX
1S
FX
1N
FX
2N
FX
1NC
FX
2NC
