Mitsubishi FX3G Series Programming Manual

860
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
37 Operation of Special Devices (M8000 -, D8000 -)
37.2 Supplement of Special Devices (M8000 - and D8000 -)
2. Special data register (D8260 to D8279)
•FX3G PLC
*1. Only a 40-point or 60-point type FX3G PLC can be connected.
Number
Operation and function
FX3G-2AD-BD FX3G-1DA-BD
Applicable
version
Ver. 1.10 or later Ver. 1.10 or later
1st analog expansion board
D 8260
Input data Ch1 Output data
D 8261
Input data Ch2 Not used
D 8262
Not used Not used
D 8263
Not used Not used
D 8264
Number of averaging times for
Ch1 (1 to 4095)
Not used
D 8265
Number of averaging times for
Ch2 (1 to 4095)
Not used
D 8266
Not used Not used
D 8267
Not used Not used
D 8268 Error status Error status
D 8269 Model code: K3 Model code: K4
2nd analog expansion board
*1
D 8270 Input data Ch1 Output data
D 8271 Input data Ch2
Not used
D 8272
Not used Not used
D 8273
Not used Not used
D 8274
Number of averaging times for
Ch1 (1 to 4095)
Not used
D 8275
Number of averaging times for
Ch2 (1 to 4095)
Not used
D 8276
Not used Not used
D 8277
Not used Not used
D 8278 Error status Error status
D 8279 Model code: K3 Model code: K4
