Mitsubishi FX3G Series Programming Manual

867
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
37 Operation of Special Devices (M8000 -, D8000 -)
37.2 Supplement of Special Devices (M8000 - and D8000 -)
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
*1. Can be connected only to FX3G PLC (40-point and 60-point type) and FX3GC PLC.
*2. The model code is "20" for the PT-ADP, and "21" for the PTW-ADP.
Number
Operation and function
FX3U-4AD-PT(W)-ADP FX3U-4AD-TC-ADP FX3U-4AD-PNK-ADP
Applicable
version
Ver. 1.00 or later Ver. 1.00 or later Ver. 1.00 or later
1st analog special adapter
D 8280
Measured temperature Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8281 Measured temperature Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8282 Measured temperature Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8283 Measured temperature Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8284
Number of averaging times
for Ch1 (1 to 4095)
Number of averaging times
for Ch1 (1 to 4095)
Number of averaging times for
Ch1 (1 to 4095)
D 8285
Number of averaging times
for Ch2 (1 to 4095)
Number of averaging times
for Ch2 (1 to 4095)
Number of averaging times for
Ch2 (1 to 4095)
D 8286
Number of averaging times
for Ch3 (1 to 4095)
Number of averaging times
for Ch3 (1 to 4095)
Number of averaging times for
Ch3 (1 to 4095)
D 8287
Number of averaging times
for Ch4 (1 to 4095)
Number of averaging times
for Ch4 (1 to 4095)
Number of averaging times for
Ch4 (1 to 4095)
D 8288 Error status Error status Error status
D 8289
Model code: K20, K21
*2
Model code: K10 Model code: K11
2nd analog special adapter
*1
D 8290 Measured temperature Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8291 Measured temperature Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8292 Measured temperature Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8293 Measured temperature Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8294
Number of averaging times
for Ch1 (1 to 4095)
Number of averaging times
for Ch1 (1 to 4095)
Number of averaging times for
Ch1 (1 to 4095)
D 8295
Number of averaging times
for Ch2 (1 to 4095)
Number of averaging times
for Ch2 (1 to 4095)
Number of averaging times for
Ch2 (1 to 4095)
D 8296
Number of averaging times
for Ch3 (1 to 4095)
Number of averaging times
for Ch3 (1 to 4095)
Number of averaging times for
Ch3 (1 to 4095)
D 8297
Number of averaging times
for Ch4 (1 to 4095)
Number of averaging times
for Ch4 (1 to 4095)
Number of averaging times for
Ch4 (1 to 4095)
D 8298 Error status Error status Error status
D 8299
Model code: K20, K21
*2
Model code: K10 Model code: K11
