A Programming Tool Applicability and Version Upgrade History
A-1 Programming Tool Applicability
31
FNC276-FNC279 Data Transfer 3
32
FNC280-FNC289 High-Speed Processing 2
33
FNC290-FNC299 Extension File Register
34
FNC300-FNC305 FX
3U
-CF-ADP
35
SFC•STL Programming
36
Interrupt Function
37
Special Device
38
Error Code
A
Version Up Information
B
Execution Times
•English version
*1. Write during RUN is not possible with a SFC program.
*2. Write during RUN is not possible with a list program or a SFC program.
Programming tool PLC Version Remarks
GX Works2
*1
(SWDNC-GXW2-E)
FX3G/FX3GC
Ver. 1.08J or later
Writing in the instruction and device ranges during RUN is supported in FX3G
PLCs earlier than Ver. 1.40.
Ver. 1.77F or later
Writing in the instruction and device ranges during RUN is supported in FX
3G
and FX3GC PLCs earlier than Ver. 1.40.
FX3U/FX3UC
Ver. 1.08J or later
Writing in the instruction and device ranges during RUN is supported in FX3U and
FX3UC PLCs earlier than Ver. 2.70.
Ver. 1.48A or later
Writing in the instruction and device ranges during RUN is supported in FX3U and
FX3UC PLCs Ver. 2.70.
GX Developer
*2
(SWD5C-GPPW-E)
FX
3G
Ver. 2.00A or later
Writing in the instruction and device ranges during RUN is supported in FX2N
PLC Ver. 1.00.
Ver. 5.00A or later
Writing in the instruction and device ranges during RUN is supported in FX
1N
PLC Ver. 1.00.
Ver. 8.72A or later
Writing in the instruction and device ranges during RUN is supported in FX3G
PLC earlier than Ver. 1.10.
Ver. 8.78G or later
Writing in the instruction and device ranges during RUN is supported in FX3G
PLC Ver. 1.10.
FX3U/FX3UC
Ver. 7.00A or later
Writing in the instruction and device ranges during RUN is supported in FX2N
PLC Ver. 3.00.
Ver. 8.18U or later
Writing in the instruction and device ranges during RUN is supported in FX3UC
PLC earlier than Ver. 2.20.
Ver. 8.24A or later
Writing in the instruction and device ranges during RUN is supported in FX3U and
FX3UC PLCs earlier than Ver. 2.30.
Ver. 8.29F or later
Writing in the instruction and device ranges during RUN is supported in FX3U and
FX3UC PLCs earlier than Ver. 2.61.
Ver. 8.82L or later
Writing in the instruction and device ranges during RUN is supported in FX3U and
FX3UC PLCs Ver. 2.61.
FX-PCS/WIN-E
*2
FX3G Ver. 3.00 or later
Writing in the instruction and device ranges during RUN is supported in FX1N
PLC Ver. 1.00.
FX3U/FX3UC
Ver. 1.00 or later
Writing in the instruction and device ranges during RUN is supported in FX2N
PLC Ver. 1.00.
Ver. 3.10 or later
Writing in the instruction and device ranges during RUN is supported in FX2N
PLC Ver. 3.00.
