Mitsubishi FX3G Series Programming Manual

929
FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
C Applied Instruction List [by Instruction Type/in Alphabetic Order]
C-1 Applied instructions [by instruction type]
C
Applicable Instruction List
D
Discontinued models
CCD FNC 84 Check Code 459
CRC FNC188 Cyclic Redundancy Check 586
LIMIT FNC256 Limit Control 655
BAND FNC257 Dead Band Control 658
ZONE FNC258 Zone Control 661
SCL FNC259
Scaling
(Coordinate by Point Data)
664
SCL2 FNC269
Scaling 2
(Coordinate by X/Y Data)
674
SORT FNC 69 Sort Tabulated Data 411
SORT2 FNC149 Sort Tabulated Data 2 536
SER FNC 61 Search a Data Stack 392
FDEL FNC210 Deleting Data from Tables 635
FINS FNC211 Inserting Data to Tables 637
10.Character string operation instructions
Mnemonic FNC No. Function
Ref.
Page
ESTR FNC116
Floating Point to Character
String Conversion
484
EVAL FNC117
Character String to
Floating Point Conversion
490
STR FNC200
BIN to Character String
Conversion
606
VAL FNC201
Character String to BIN
Conversion
611
DABIN FNC260
Decimal ASCII to
BIN Conversion
668
BINDA FNC261
BIN to Decimal ASCII
Conversion
671
ASCI FNC 82
Hexadecimal to ASCII
Conversion
453
HEX FNC 83
ASCII to Hexadecimal
Conversion
456
$MOV FNC209 Character String Transfer 632
$+ FNC202 Link Character Strings 616
LEN FNC203
Character String Length
Detection
618
RIGHT FNC204
Extracting Character String
Data From the Right
620
LEFT FNC205
Extracting Character String
Data from the Left
622
MIDR FNC206
Random Selection of
Character Strings
624
MIDW FNC207
Random Replacement of
Character Strings
627
INSTR FNC208 Character string search 630
COMRD FNC182
Read Device Comment
Data
581
11.Program flow control instructions
Mnemonic FNC No. Function
Ref.
Page
CJ FNC 00 Conditional Jump 215
CALL FNC 01 Call Subroutine 222
SRET FNC 02 Subroutine Return 226
IRET FNC 03 Interrupt Return 227
EI FNC 04 Enable Interrupt 229
9. Data operation instructions
Mnemonic FNC No. Function
Ref.
Page
DI FNC 05 Disable Interrupt 230
FEND FNC 06 Main Routine Program End 231
FOR FNC 08 Start a FOR/NEXT Loop 235
NEXT FNC 09 End a FOR/NEXT Loop 236
12.I/O refresh instructions
Mnemonic FNC No. Function
Ref.
Page
REF FNC 50 Refresh 332
REFF FNC 51 Refresh and Filter Adjust 336
13.Real time clock control instructions
Mnemonic FNC No. Function
Ref.
Page
TCMP FNC160 RTC Data Compare 556
TZCP FNC161 RTC Data Zone Compare 558
TADD FNC162 RTC Data Addition 560
TSUB FNC163 RTC Data Subtraction 562
TRD FNC166 Read RTC data 568
TWR FNC167 Set RTC data 569
HTOS FNC164
Hour to Second
Conversion
564
STOH FNC165
Second to Hour
Conversion
566
14.Pulse output/positioning control
instructions
Mnemonic FNC No. Function
Ref.
Page
ABS FNC155
Absolute Current Value
Read
546
DSZR FNC150 DOG Search Zero Return 541
ZRN FNC156 Zero Return 547
TBL FNC152
Batch Data Positioning
Mode
545
DVIT FNC151 Interrupt Positioning 543
DRVI FNC158 Drive to Increment 551
DRVA FNC159 Drive to Absolute 553
PLSV FNC157
Variable Speed Pulse
Output
549
PLSY FNC 57 Pulse Y Output 368
PLSR FNC 59
Acceleration/Deceleration
Setup
376
15.Serial communication instructions
Mnemonic FNC No. Function
Ref.
Page
RS FNC 80 Serial Communication 449
RS2 FNC 87 Serial Communication 2 466
IVCK FNC270 Inverter Status Check 679
IVDR FNC271 Inverter Drive 681
IVRD FNC272 Inverter Parameter Read 683
IVWR FNC273 Inverter Parameter Write 685
IVBWR FNC274
Inverter Parameter
Block Write
687
IVMC FNC275 Inverter Multi Command 689
11.Program flow control instructions
Mnemonic FNC No. Function
Ref.
Page

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
