1 Introduction
1.1 Outline and Features of Analog Control
FX 3G /FX 3U /FX 3UC PLC User's Manual - Analog Control Edition
Common Items
1.1 Outline and Features of Analog Control
1.1.3 Temperature sensor input control
Use the PLC to check the workpiece/machine temperature measured with a thermocouple or platinum
resistance thermometer sensor.
→ To determine whether or not a unit can be connected to the PLC, refer to Chapter 3 "System
Configuration Drawings of Analog Products."
FX
3U Series Temperature sensor input products
•FX
3U-4AD-PT-ADP
→ For detailed description, refer to Section H.
•FX
3U-4AD-PTW-ADP
→ For detailed description, refer to Section I.
•FX
3U-4AD-PNK-ADP
→ For detailed description, refer to Section J.
•FX
3U-4AD-TC-ADP
→ For detailed description, refer to Section K.
Other Series Temperature sensor input products
•FX
2N-8AD • FX2N-2LC
•FX
2N-4AD-TC • FX2N-4AD-PT
→ For a detailed description of the other temperature sensor input products, refer to the
corresponding manuals.
Temperature data
(Analog data)
Temperature
sensor input,
special function
block or special
adapter
Temperature data
(Digital value)
Check the temperature
using the PLC.
Measure the
temperature of the
equipment.
FX3U/FX3UC Series PLC/FX3G
