A-18
3 System Configuration Drawings of Analog Products
3.3 FX3G Series PLC
FX 3G /FX 3U /FX 3UC PLC User's Manual - Analog Control Edition
Common Items
3.3 FX3G Series PLC
3.3 FX3G Series PLC
3.3.1 Connection of expansion boards, special adapters
1. FX3G Series PLC (14-point, 24-point type)
and represent the connecting positions.
For a detailed description of installation, refer to the following manual
supplied with your PLC.
FX 3G Series
Refer to the FX
3G Series User's Manual - Hardware Edition.
European terminal block
European terminal block
European terminal block
Analog input
Flowmeter
Pressure sensor
Signal converter, etc.
Analog output
Inverter, etc.
Temperature sensor
input
Thermocouple
(types K and J)
Resistance
thermometer sensor
(Pt1000 and Ni1000)
Platinum resistance
thermometer
sensor (Pt100)
Up to 1 analog expansion board, analog special adapters can be connected.
FX 3G -CNV-ADP
FX
3U -4AD-ADP
1st
adapter
1st
board
1st
board
European terminal block
Analog output
Inverter, etc.
FX 3G -1DA-BD
European terminal block
Analog input
Flowmeter
Pressure sensor
Signal converter, etc.
FX 3G -2AD-BD
1st
adapter
1st
adapter
FX
3U -4DA-ADP
FX 3U -4AD-TC-ADP
FX
3U -4AD-PNK-ADP
FX
3U -4AD-PT-ADP
FX
3U -4AD-PTW-ADP
