3.5 Grounding
FX
3G
/FX
3U
/FX
3UC
PLC User's Manual - Analog Control Edition
FX3U-4AD/FX3UC-4AD (4-channel Analog Input)
3.4.2 FX3UC-4AD
*1. Use the 2-core shielded twisted pair cable for the analog input lines, and separate the analog input
lines from the other motive power lines or inductive lines.
*2. To use the current input, be sure to short circuit the line between the Vîš… + terminal and the Iîš…
+ terminal (îš… : channel number).
*3. The SLD and " " terminals are connected to each other inside.
*4. Do not connect any lines to the "•" terminal.
3.5 Grounding
Grounding should be performed as stated below.
• The grounding resistance should be 100Ω or less.
• Independent grounding should be performed for best results.
When independent grounding is not performed, perform "shared grounding" as shown in the following
figure.
→ For details, refer to the User’s Manual - Hardware Edition of each Series.
• Use the following grounding wire.
• The PLC grounding point should be close, and all grounding wires should be as short as possible.
FX3U-4AD
AWG14 (2mm
2
)
FX
3UC-4AD
AWG22-20 (0.3 to 0.5mm
2
)
250
Ω
6.8k
Ω
ch
îš…
200k
Ω
FX
3UC
-4AD
V
îš…
+, I
îš…
+, ch
îš…
:
îš…
represents the channel number.
Terminal
block
I
îš…
+
COM
îš…
V
îš…
+
*1
I
îš…
+
COM
îš…
V
îš…
+
250
Ω
6.8k
Ω
ch
îš…
200k
Ω
*1
If current input is
selected
If voltage input is
selected
*2
•
SLD
SLD
*3
*4
Class-D
grounding
PLC
Other
equipment
PLC
Other
equipment
PLC
Other
equipment
Shared grounding
Good condition
Common grounding
Not allowed
Independent grounding
Best condition
