Service
-
157
-
'10
•
HM-T-149
10 - High Supply temp. 1, 11 High Supply temp. 2
YES
YES
Connect it correctly.
NO
NO
Is the supply water temperature sensor
for the relevant system correctly
connected?
Are the characteristics for the
sensor OK? (See “Temperature
sensor” section)
Replace the EBV board (AA22).
Defective sensor - replace.
Troubleshooting guide
157
159
