7. APPLICATION INSTRUCTIONS
7 − 22
MELSEC-A
7.2 Rotation Instructions
The rotation instructions rotate the data stored in the accumulator.
Classification
Instruction
Symbol
Ref. Page Classification
Instruction
Symbol
Ref. Page
ROR 7-23 ROL 7-25
RORP 7-23 ROLP 7-25
RCR 7-23 RCL 7-25
RCRP 7-23 RCLP 7-25
DROR 7-27 DROL 7-29
DRORP 7-27 DROLP 7-29
DRCR 7-27 DRCL 7-29
Right rotation
DRCRP 7-27
Left rotation
DRCLP 7-29
