Mitsubishi MELSEC-A series Programming Manual

8. MICROCOMPUTER MODE
8 − 16
MELSEC-A
Device
CPU
Type
Address
Extension
file register
(R)
block No.
10 to 28
A2
A2-S1
A3
A2N
A2N-S1
A3N
A3H
A3M
A3V
A73
A3N board
Block No. Head address
11 38000
H
10 3C000
H
Memory cassette
When A3MCA-16 is used
Block No. Head address
28 A0000
27 A4000H
26 A8000H
25 AC000H
24 B0000H
23 B4000H
22 B8000H
21 BC000H
20 C0000H
19 C4000H
18 C8000H
17 CC000H
16 D0000H
15 D4000H
14 D8000H
13 DC000H
12 E4000H
11 E8000H
10 EC000H
When A3NMCA-24, 40 or 56 is used
