APPENDICES
APP − 67
MELSEC-A
POINTS
(1) All the application instructions indicated above are used without index
qualification.
(2) When unexecuted, any instruction is processed during the following time:
An, A2C and A0J2H..................................(Number of steps+1) x 1.25 (µs)
AnN, AnS, A3V, A73 and A3N board ........(Number of steps+1) x 1.0 (µs)
A1SH, A1SJH ...........................................(Number of steps+1) x 0.33 (µs)
A2SH (S1), A1FX......................................(Number of steps+1) x 0.25 (µs)
A3H, A3M..................................................(Number of steps+1) x 0.2 (µs)
A2A, A2AS, and A2U................................(Number of steps+4) x 0.2 (µs)
A3A, A3U, and A4U ..................................(Number of steps+4) x 0.15 (µs)
A2USH-S1, A2USH board........................(Number of steps+1) x 0.09 (µs)
