Mitsubishi MELSEC Q Series Programming Manual

12-84
7011
[MULTI EXE. ERROR]
Either of the following settings was made in a
multiple CPU system.
• Multiple CPU automatic refresh setting was
made for the inapplicable CPU module.
• "I/O sharing when using multiple CPUs" setting
was made for the inapplicable CPU module.
■Collateral information
• Common information: Module No. (CPU No.)
• Individual information:-
■Diagnostic Timing
• At power-on/At reset
• Correct the multiple CPU automatic refresh
setting.
• Correct the "I/O sharing when using multiple
CPUs" setting.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
Q00/Q01
*8
QnU
*18
[MULTI EXE. ERROR]
The system configuration for using the Multiple
CPU high speed transmission function is not met.
• The QnUCPU is not used for the CPU No.1.
• The Multiple CPU high speed main base unit
(Q3DB) is not used.
• Points other than 0 is set to the send range for
the CPU module incompatible with the multiple
CPU high speed transmission function.
• Points other than 0 is set to the send range for
the CPU module incompatible with the multiple
CPU.
■Collateral information
• Common information: Module No. (CPU No.)
• Individual information:-
■Diagnostic Timing
• At power-on/At reset
• Change the system configuration to meet the
conditions for using the Multiple CPU high
speed transmission function.
• Set the send range of CPU, that does not
correspond to multiple CPU compatible area, at
0 point, when performing automatic refreshing in
multiple CPU compatible area.
QnU
*20
7013
[MULTI EXE. ERROR]
The Q172(H)CPU(N) or Q173(H)CPU(N) is
mounted to the CPU slot or slots 0 to 2. (This may
result in a module failure.)
■Collateral information
• Common information: Module No. (CPU No.)
• Individual information:-
■Diagnostic Timing
• At power-on/At reset
• Check the QCPU and Motion CPU that can be
used in a multiple CPU system, and change the
system configuration.
• Remove the Motion CPU incompatible with the
multiple CPU system.
QnU
7020
[MULTI CPU ERROR]
In a multiple CPU system, an error occurred in the
CPU module where "All station stop by stop error
of CPU" was not selected in the operating mode
setting.
(The CPU module where no error occurred was
used to detect an error.)
■Collateral information
• Common information: Module No. (CPU No.)
• Individual information:-
■Diagnostic Timing
• Always
Read the individual information of the error using
the programming tool. Check the error in the CPU
module, and remove the error.
RUN:
On
ERR.:
On
CPU Status:
Continue
Q00/Q01
*8
Qn(H)
*8
QnPH
QnU
*18
7030
[CPU LAY ERROR]
An assignment error occurred in the CPU-
mountable slot (CPU slot, I/O slot 0, 1) in excess of
the number of CPU modules specified in the
multiple CPU setting of the PLC parameter dialog
box.
■Collateral information
• Common information: Module No. (CPU No.)
• Individual information:-
■Diagnostic Timing
• At power-on/At reset
• Set the same value to the number of CPU
modules specified in the multiple CPU setting of
the PLC parameter dialog box and the number
of mounted CPU modules (including CPU
(empty)).
• Make the type specified in the I/O assignment
setting of the PLC parameter dialog box
consistent with the CPU module configuration.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
Q00J/Q00/Q01
*8
QnU
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
