Mitsubishi MELSEC Q Series Programming Manual

App-22
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
OUT
When not changed
(OFF OFF)
0.158 0.068 0.068 0.068
(ON ON)
When changed
(OFF ON)
0.158 0.068 0.068 0.068
(ON OFF)
F
When OFF 2.8 1.2 1.2 1.2
When
ON
When displayed 162 69.7 69.7 69.7
Display completed 126 54 54 54
T
When not executed 0.63 0.27 0.27 0.27
When
executed
After time up 0.63 0.27 0.27 0.27
When added
K 0.63 0.27 0.27 0.27
D 0.63 0.27 0.27 0.27
C
When not executed 0.63 0.27 0.27 0.27
When
executed
After time up 0.63 0.27 0.27 0.27
When added
K 0.63 0.27 0.27 0.27
D 0.63 0.27 0.27 0.27
OUTH
T
When not executed 0.63 0.27 0.27 0.27
When
executed
After time up 0.63 0.27 0.27 0.27
When added
K 0.63 0.27 0.27 0.27
D 0.63 0.27 0.27 0.27
SET
When not executed 0.158 0.068 0.068 0.068
When executed
When not changed (ON ON)
0.158 0.068 0.068 0.068
When changed (OFF ON)
0.158 0.068 0.068 0.068
F
When not executed 0.47 0.20 0.20 0.20
When
executed
When displayed 161 69 69 69
Display completed 0.47 0.20 0.20 0.20
RST
When not executed 0.158 0.068 0.068 0.068
When executed
When not changed (OFF OFF)
0.158 0.068 0.068 0.068
When changed (ON OFF)
0.158 0.068 0.068 0.068
SM
When not executed 0.158 0.068 0.068 0.068
When executed 0.158 0.068 0.068 0.068
F
When not executed 0.47 0.20 0.20 0.20
When
executed
When displayed 90383838
Display completed 0.47 0.20 0.20 0.20
T, C
When not executed 0.63 0.27 0.27 0.27
When executed 0.63 0.27 0.27 0.27
D
When not executed 0.24 0.10 0.10 0.10
When executed 0.24 0.10 0.10 0.10
Z
When not executed 0.47 0.20 0.20 0.20
When executed 4.3 1.9 1.9 1.9
R
When not executed 0.40 0.17 0.17 0.17
When executed 0.40 0.17 0.17 0.17
PLS
PLF
––
1.0 0.44 0.44 0.44
FF
Y
When not executed 0.47 0.20 0.20 0.20
When executed 0.47 0.20 0.20 0.20
DELTA
DELTAP
DY0
When not executed 0.47 0.20 0.20 0.20
When executed 5.9 2.6 2.6 2.6
