Mitsubishi MELSEC Q Series Programming Manual

App-23
8
8
8
8
A
6
7
8
Appendix1 OPERATION PROCESSING TIME Appendix 1.3
Operation Processing Time of High Performance Model QCPU/Process CPU/Redundant CPU
Instruction Condition (Device)
Processing Time (µs)
Qn QnH QnPH QnPRH
SFT
SFTP
When not executed 0.47 0.20 0.20 0.20
When executed 1.66 0.71 0.71 0.71
MC
––
0.24 0.10 0.10 0.10
MCR
––
0.079 0.034 0.034 0.034
FEND
END
Error check performed 380 150 150 500
No error check performed
(• Battery check)
(• Fuse blown check)
(• I/O module verification)
380 150 150 500
NOP
––
0.079 0.034 0.034 0.034
NOPLF
PAGE
––
0.079 0.034 0.034 0.034
