App-92
Category Instruction Condition (Device)
Processing Time (µs)
Q03UD(E)CPU
Q04/
Q06UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Min. Max. Min. Max. Min. Max.
Basic
instruction
LDED<
Double
precision
In conductive status 4.300 8.300 3.800 7.600 3.800 7.600
In non-conductive status
3.700 7.900 3.500 7.400 3.500 7.400
ANDED<
Double
precision
When not executed
When
executed
In conductive status 0.060 0.0285 0.0285
In non-conductive status 3.800 7.800 3.300 7.300 3.300 7.300
ORED<
Double
precision
When not executed 3.900 7.900 3.400 3.900 3.400 3.900
When
executed
In conductive status 0.060 0.0285 0.0285
In non-conductive status 4.100 9.600 3.700 9.200 3.700 9.200
LDED>=
Double
precision
In conductive status 4.000 9.600 3.700 9.200 3.700 9.200
In non-conductive status 4.100 9.600 3.600 9.000 3.600 9.000
ANDED>=
Double
precision
When not executed
4.100 9.600 3.600 8.900 3.600 8.900
When
executed
In conductive status
In non-conductive status 0.060 0.0285 0.0285
ORED>=
Double
precision
When not executed 3.800 7.900 3.400 7.400 3.400 7.400
When
executed
In conductive status 3.900 8.100 3.400 7.500 3.400 7.500
In non-conductive status 0.060 0.0285 0.0285
LD$=
In conductive status 4.100 9.600 3.700 9.200 3.700 9.200
In non-conductive status 4.000 7.200 3.600 6.600 3.600 6.600
AND$=
When not executed 5.300 8.900 4.700 8.100 4.700 8.100
When executed
In conductive status 4.700 9.000 4.200 8.200 4.200 8.200
In non-conductive status 0.060 0.0285 0.0285
OR$=
When not executed 4.400 6.800 3.900 6.400 3.900 6.400
When executed
In conductive status 4.500 6.700 4.000 6.300 4.000 6.300
In non-conductive status 0.060 0.0285 0.0285
LD$< >
In conductive status 5.100 8.200 4.200 7.600 4.200 7.600
In non-conductive status 5.000 8.100 4.000 7.200 4.000 7.200
AND$< >
When not executed 4.800 8.100 4.300 7.500 4.300 7.500
When executed
In conductive status 4.700 8.400 4.200 7.800 4.200 7.800
In non-conductive status 0.060 0.0285 0.0285
OR$< >
When not executed 4.300 5.500 4.100 5.100 4.100 5.100
When executed
In conductive status 4.500 5.900 4.400 5.400 4.400 5.400
In non-conductive status 0.060 0.0285 0.0285
LD$>
In conductive status 5.200 7.300 4.100 6.700 4.100 6.700
In non-conductive status 5.100 7.200 4.100 6.700 4.100 6.700
AND$>
When not executed 4.800 7.200 4.300 6.700 4.300 6.700
When executed
In conductive status 4.800 7.700 4.200 7.100 4.200 7.100
In non-conductive status 0.060 0.0285 0.0285
OR$>
When not executed 4.500 7.100 4.000 6.700 4.000 6.700
When executed
In conductive status 4.600 7.600 4.300 7.000 4.300 7.000
In non-conductive status 0.060 0.0285 0.0285
LD$<=
In conductive status 5.100 6.800 4.300 6.200 4.300 6.200
In non-conductive status 5.200 7.200 4.300 6.600 4.300 6.600
AND$<=
When not executed 5.000 6.300 4.400 5.700 4.400 5.700
When executed
In conductive status 4.800 6.400 4.200 5.800 4.200 5.800
In non-conductive status 0.060 0.0285 0.0285
