Appendix1 OPERATION PROCESSING TIME Appendix 1.4 Operation Processing Time of Universal Model QCPU
Category Instruction Condition (Device)
Processing Time (µs)
Q03UD(E)CPU
Q04/
Q06UD(E)HCPU
Q10/Q13/Q20/
Q26UD(E)HCPU
Min. Max. Min. Max. Min. Max.
Basic
instruction
OR$<=
When not executed
0.060 0.0285 0.0285
When
executed
In conductive status
4.700 7.700 4.400 7.200 4.400 7.200
In non-conductive status
4.600 7.600 4.400 7.100 4.400 7.100
LD$<
In conductive status
4.800 8.100 4.500 7.500 4.500 7.500
In non-conductive status
5.000 8.300 4.500 7.900 4.500 7.900
AND$<
When not executed
0.060 0.0285 0.0285
When
executed
In conductive status
4.500 7.100 4.000 6.600 4.000 6.600
In non-conductive status
4.900 7.500 4.400 7.100 4.400 7.100
OR$<
When not executed
0.060 0.0285 0.0285
When
executed
In conductive status
5.100 7.800 4.100 7.200 4.100 7.200
In non-conductive status
5.000 8.100 4.100 7.600 4.100 7.600
LD$>=
In conductive status
4.800 6.700 4.500 6.200 4.500 6.200
In non-conductive status
5.000 6.700 4.400 6.300 4.400 6.300
AND$>=
When not executed
0.060 0.0285 0.0285
When
executed
In conductive status
4.400 6.800 4.100 6.300 4.100 6.300
In non-conductive status
4.500 7.000 4.200 6.600 4.200 6.600
OR$>=
When not executed
0.060 0.0285 0.0285
When
executed
In conductive status
5.400 6.600 4.100 5.800 4.100 5.800
In non-conductive status
5.300 6.300 4.100 5.700 4.100 5.700
BKCMP = n
n = 1 8.200 10.700 7.500 10.000 7.500 10.000
n = 96 57.400 61.800 46.400 48.700 46.400 48.700
BKCMP<> n
n = 1 8.200 10.700 7.500 10.000 7.500 10.000
n = 96 59.500 63.300 45.600 50.400 45.600 50.400
BKCMP> n
n = 1 8.200 10.800 7.500 10.100 7.500 10.100
n = 96 59.500 63.400 47.700 50.500 47.700 50.500
BKCMP<= n
n = 1 8.200 10.600 7.500 10.000 7.500 10.000
n = 96 57.400 61.700 46.400 49.000 46.400 49.000
BKCMP< n
n = 1 8.300 10.600 7.500 10.000 7.500 10.000
n = 96 59.500 63.600 47.600 50.500 47.600 50.500
BKCMP>= n
n = 1 8.200 10.900 7.500 10.000 7.500 10.000
n = 96 57.400 62.000 46.400 48.900 46.400 48.900
DBKCMP = n
n = 1 9.250 14.000 8.600 13.000 8.600 13.000
n = 96 60.700 67.500 47.900 52.800 47.900 52.800
DBKCMP<> n
n = 1 9.250 14.000 8.600 13.000 8.600 13.000
n = 96 60.700 67.500 47.900 52.800 47.900 52.800
DBKCMP> n
n = 1 9.250 14.000 8.600 13.000 8.600 13.000
n = 96 60.700 67.500 47.900 52.800 47.900 52.800
DBKCMP<= n
n = 1 9.250 14.000 8.600 13.000 8.600 13.000
n = 96 60.700 67.500 47.900 52.800 47.900 52.800
DBKCMP< n
n = 1 9.250 14.000 8.600 13.000 8.600 13.000
n = 96 60.700 67.500 47.900 52.800 47.900 52.800
DBKCMP>= n
n = 1 9.250 14.000 8.600 13.000 8.600 13.000
n = 96 60.700 67.500 47.900 52.800 47.900 52.800
