App-112
(2) Table of the time to be added when file register, module access device or link direct device is used
(a) When using Q00UJCPU, Q00UCPUI, Q01UCPU and Q02UCPU
Device name data
Device Specification
Location
Processing Time (µs)
Q00UJCPU Q00UCPU Q01UCPU Q02UCPU
File register (R)
When standard
RAM is used
Bit
Source 0.100 0.100 0.100 0.100
Destination 0.100 0.100 0.100 0.100
Word
Source 0.100 0.100 0.100 0.100
Destination 0.100 0.100 0.100 0.100
Double word
Source 0.100 0.100 0.100 0.200
Destination 0.100 0.100 0.100 0.200
When SRAM
card is used
(Q2MEM-1MBS,
Q2MEM-2MBS)
Bit
Source
–– –– ––
0.220
Destination
–– –– ––
0.180
Word
Source
–– –– ––
0.220
Destination
–– –– ––
0.180
Double word
Source
–– –– ––
0.440
Destination
–– –– ––
0.380
When SRAM
card is used
(Q3MEM-4MBS,
Q3MEM-8MBS)
Bit
Source
–– –– ––
0.160
Destination
–– –– ––
0.140
Word
Source
–– –– ––
0.160
Destination
–– –– ––
0.140
Double word
Source
–– –– ––
0.320
Destination
–– –– ––
0.300
File register (ZR)
When standard
RAM is used
Bit
Source 0.120 0.120 0.120 0.120
Destination 0.120 0.120 0.120 0.120
Word
Source 0.120 0.120 0.120 0.120
Destination 0.120 0.120 0.120 0.120
Double word
Source 0.120 0.120 0.120 0.220
Destination 0.120 0.120 0.120 0.220
When SRAM
card is used
(Q2MEM-1MBS,
Q2MEM-2MBS)
Bit
Source
–– –– ––
0.240
Destination
–– –– ––
0.200
Word
Source
–– –– ––
0.240
Destination
–– –– ––
0.200
Double word
Source
–– –– ––
0.460
Destination
–– –– ––
0.400
When SRAM
card is used
(Q3MEM-4MBS,
Q3MEM-8MBS)
Bit
Source
–– –– ––
0.180
Destination
–– –– ––
0.160
Word
Source
–– –– ––
0.180
Destination
–– –– ––
0.160
Double word
Source
–– –– ––
0.340
Destination
–– –– ––
0.320
Module access device
(Un\G , U3En\G0 to G4095)
Bit
Source
–– –– ––
12.000
Destination
–– –– ––
17.300
Word
Source
–– –– ––
9.700
Destination
–– –– ––
33.000
Double word
Source
–– –– ––
24.200
Destination
–– –– ––
34.800
Link direct device
(Jn\ )
Bit
Source
–– –– ––
32.900
Destination
–– –– ––
67.300
Word
Source
–– –– ––
37.200
Destination
–– –– ––
37.000
Double word
Source
–– –– ––
39.500
Destination
–– –– ––
41.900
