Appendix1 OPERATION PROCESSING TIME Appendix 1.5 Operation Processing Time of LCPU
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU L26CPU-BT
Min. Max. Min. Max.
Basic
instruction
LD=
In conductive status
0.120 0.0285
In non-conductive status
AND=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
OR=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LD<>
In conductive status
0.120 0.0285
In non-conductive status
AND<>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
OR<>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LD>
In conductive status
0.120 0.0285
In non-conductive status
AND>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
OR>
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LD<=
In conductive status
0.120 0.0285
In non-conductive status
AND<=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
OR<=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LD<
In conductive status
0.120 0.0285
In non-conductive status
AND<
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
OR<
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
LD>=
In conductive status
0.120 0.0285
In non-conductive status
AND>=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
OR>=
When not executed
0.120 0.0285
When executed
In conductive status
In non-conductive status
