Mitsubishi MELSEC Q Series Programming Manual

App-119
8
8
8
8
A
6
7
8
Appendix1 OPERATION PROCESSING TIME Appendix 1.5 Operation Processing Time of LCPU
Remark
For the instructions for which a leading edge instruction ( P) is not described,
the processing time is the same as an ON execution instruction.
MOVP instruction, WANDP instruction etc.
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU L26CPU-BT
Min. Max. Min. Max.
Application
instruction
ROR n
n = 1 2.200 4.900 1.700 2.500
n = 15 2.200 4.900 1.700 2.500
RCR n
n = 1 2.100 4.800 1.700 3.200
n = 15 2.100 4.800 1.700 3.200
ROL n
n = 1 2.100 4.800 1.800 3.200
n = 15 2.100 4.800 1.800 3.200
RCL n
n = 1 2.100 5.200 1.800 2.200
n = 15 2.100 5.200 1.800 2.200
DROR n
n = 1 2.200 5.200 1.900 2.700
n = 31 2.200 5.200 1.900 2.700
DRCR n
n = 1 2.200 5.900 1.900 4.200
n = 31 2.200 5.900 1.900 4.200
DROL n
n = 1 2.200 4.900 1.800 3.300
n = 31 2.200 4.900 1.800 3.300
DRCL n
n = 1 2.200 5.900 1.900 3.800
n = 31 2.200 5.900 1.900 3.800
SFR n
n = 1 2.200 4.600 1.700 2.600
n = 15 2.200 4.600 1.700 2.600
SFL n
n = 1 2.200 4.600 1.800 2.700
n = 15 2.200 4.600 1.800 2.700
DSFR n
n = 1 2.200 6.100 2.200 4.300
n = 96 33.400 38.100 23.900 26.100
DSFL n
n = 1 2.200 6.100 2.100 4.000
n = 96 33.500 38.000 23.700 25.800
SUM
= 0
3.000 4.800 2.900 3.600
= FFFF
H
3.000 4.900 2.900 3.600
SEG
When executed 1.700 3.600 1.500 2.100
FOR
–
1.300 3.200 0.870 2.100
CALL Pn
Internal file pointer 2.600 4.000 2.300 3.600
Common pointer 4.600 13.500 3.200 4.900
CALL Pn to
–
31.200 36.000 26.100 29.300
D
D
D
D
D
D
D
D
D
D
D
D
S
S
S1
S5
Example
