Mitsubishi MELSEC Q Series Programming Manual

App-125
8
8
8
8
A
6
7
8
Appendix1 OPERATION PROCESSING TIME Appendix 1.5 Operation Processing Time of LCPU
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU L26CPU-BT
Min. Max. Min. Max.
Basic
instruction
OR$<=
When not executed
0.120 0.0285
When
executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
LD$<
In conductive status
5.600 17.100 4.200 8.200
In non-conductive status
5.600 17.100 4.200 8.200
AND$<
When not executed
0.120 0.0285
When
executed
In conductive status
5.300 16.400 3.900 7.300
In non-conductive status
5.300 16.400 3.900 7.300
OR$<
When not executed
0.120 0.0285
When
executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
LD$>=
In conductive status
5.600 17.100 4.200 8.200
In non-conductive status
5.600 17.100 4.200 8.200
AND$>=
When not executed
0.120 0.0285
When
executed
In conductive status
5.300 16.400 3.900 7.300
In non-conductive status
5.300 16.400 3.900 7.300
OR$>=
When not executed
0.120 0.0285
When
executed
In conductive status
5.200 15.700 4.000 7.600
In non-conductive status
5.200 15.700 4.000 7.600
BKCMP = n
n = 1 9.200 15.600 7.500 10.100
n = 96 60.700 69.100 45.600 50.500
BKCMP<> n
n = 1 9.200 15.600 7.500 10.100
n = 96 60.700 69.100 45.600 50.500
BKCMP> n
n = 1 9.200 15.600 7.500 10.100
n = 96 60.700 69.100 45.600 50.500
BKCMP<= n
n = 1 9.200 15.600 7.500 10.100
n = 96 60.700 69.100 45.600 50.500
BKCMP< n
n = 1 9.200 15.600 7.500 10.100
n = 96 60.700 69.100 45.600 50.500
BKCMP>= n
n = 1 9.200 15.600 7.500 10.100
n = 96 60.700 69.100 45.600 50.500
DBKCMP = n
n = 1 9.700 16.400 8.600 13.000
n = 96 61.200 69.900 47.900 52.800
DBKCMP<> n
n = 1 9.700 16.400 8.600 13.000
n = 96 61.200 69.900 47.900 52.800
DBKCMP> n
n = 1 9.700 16.400 8.600 13.000
n = 96 61.200 69.900 47.900 52.800
DBKCMP<= n
n = 1 9.700 16.400 8.600 13.000
n = 96 61.200 69.900 47.900 52.800
DBKCMP< n
n = 1 9.700 16.400 8.600 13.000
n = 96 61.200 69.900 47.900 52.800
DBKCMP>= n
n = 1 9.700 16.400 8.600 13.000
n = 96 61.200 69.900 47.900 52.800
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
S1
S2
D
