Mitsubishi MELSEC Q Series Programming Manual

App-124
Category Instruction Condition (Device)
Processing Time (µs)
L02CPU L26CPU-BT
Min. Max. Min. Max.
Basic
instruction
LDED<
Double
precision
In conductive status 4.800 16.000 3.500 9.000
In non-conductive status 4.800 16.000 3.500 9.000
ANDED<
Double
precision
When not executed 0.120 0.0285
When
executed
In conductive status 4.400 15.100 3.200 7.500
In non-conductive status 4.400 15.100 3.200 7.500
ORED<
Double
precision
When not executed 0.120 0.0285
When
executed
In conductive status 4.500 14.900 3.400 9.200
In non-conductive status 4.500 14.900 3.400 9.200
LDED>=
Double
precision
In conductive status 4.800 16.000 3.500 9.000
In non-conductive status 4.800 16.000 3.500 9.000
ANDED>=
Double
precision
When not executed 0.120 0.0285
When
executed
In conductive status 4.400 15.100 3.200 7.500
In non-conductive status 4.400 15.100 3.200 7.500
ORED>=
Double
precision
When not executed 0.120 0.0285
When
executed
In conductive status 4.500 14.900 3.400 9.200
In non-conductive status 4.500 14.900 3.400 9.200
LD$=
In conductive status 5.600 17.100 4.200 8.200
In non-conductive status 5.600 17.100 4.200 8.200
AND$=
When not executed 0.120 0.0285
When executed
In conductive status 5.300 16.400 3.900 7.300
In non-conductive status 5.300 16.400 3.900 7.300
OR$=
When not executed 0.120 0.0285
When executed
In conductive status 5.200 15.700 4.000 7.600
In non-conductive status 5.200 15.700 4.000 7.600
LD$< >
In conductive status 5.600 17.100 4.200 8.200
In non-conductive status 5.600 17.100 4.200 8.200
AND$< >
When not executed 0.120 0.0285
When executed
In conductive status 5.300 16.400 3.900 7.300
In non-conductive status 5.300 16.400 3.900 7.300
OR$< >
When not executed 0.120 0.0285
When executed
In conductive status 5.200 15.700 4.000 7.600
In non-conductive status 5.200 15.700 4.000 7.600
LD$>
In conductive status 5.600 17.100 4.200 8.200
In non-conductive status 5.600 17.100 4.200 8.200
AND$>
When not executed 0.120 0.0285
When executed
In conductive status 5.300 16.400 3.900 7.300
In non-conductive status 5.300 16.400 3.900 7.300
OR$>
When not executed 0.120 0.0285
When executed
In conductive status 5.200 15.700 4.000 7.600
In non-conductive status 5.200 15.700 4.000 7.600
LD$<=
In conductive status 5.600 17.100 4.200 8.200
In non-conductive status 5.600 17.100 4.200 8.200
AND$<=
When not executed 0.120 0.0285
When executed
In conductive status 5.300 16.400 3.900 7.300
In non-conductive status 5.300 16.400 3.900 7.300
