App-156
SM325
Output mode at
block stop
OFF : OFF
ON : Preserves
Select whether the coil outputs of the active
steps are held or not at the time of a block
stop.
• The initial value is set to off when the
output mode at a block stop is off in the
parameter setting, and it is set to on when
the coil outputs are set to be held.
• When this relay is turned off, all coil outputs
are turned off.
• When this relay is turned on, the coil output
state is held.
S (Initial)/U M9196
Q00J/Q00/Q01
*1
Qn(H)
QnPH
QnPRH
QnU
LCPU
SM326
SFC device clear
mode
OFF : Clear device
ON : Preserves device
Select the device status at the time of
switching from STOP to program write, and
then to RUN. (All devices except the step
relay)
U
New
SM327
Output during end
step execution
OFF : Hold step output
turned OFF
(cleared)
ON : Hold step output
held
If this relay is off, the coil output turns off
when the step held after transition (SC, SE, or
ST) reaches the end step.
S (Initial)/U
Qn(H)
QnPH
QnPRH
QnU
LCPU
U
Q00J/Q00/Q01
*1
SM328
Clear processing
mode when end
step is reached
OFF : Clear processing
is performed.
ON : Clear processing
is not performed.
Select whether clear processing will be
performed or not if active steps other than the
ones being held exist in the block when the
end step is reached.
• When this relay turns OFF, all active steps
are forcibly terminated to terminate the
block.
• When this relay is ON, the execution of the
block is continued as-is.
• If active steps other than the ones being
held do not exist when the end step is
reached, the steps being held are
terminated to terminate the block.
Q00J/Q00/Q01
*1
QnU
LCPU
SM330
Operation mode
for low speed
execution type
program
OFF : Asynchronous
mode
ON : Synchronous
mode
Select whether the low speed execution type
program will be executed in the
asynchronous mode or in the synchronous
mode.
• Asynchronous mode (this relay is turned
off.) The operation of the low-speed
execution type program is performed
continuously within an excess time.
• Synchronous mode (this relay is turned
on.) The operation of the low-speed
execution type program is not performed
continuously, but performed from the next
scan, even if there is excess time.
U
Qn(H)
QnPH
SM331
Normal SFC
program
execution status
OFF : Not executed
ON : Being executed
• This relay stores the information on
whether the normal SFC program is in
execution or not.
• Used as an interlock for execution of the
SFC control instruction.
S (Status
change)
Qn(H)
*3
QnPH
*4
QnPRH
SM332
Program
execution
management SFC
program
execution status
OFF : Not executed
ON : Being executed
• This relay stores the information on
whether the SFC program for program
execution management is in execution or
not.
• Used as an interlock for execution of the
SFC control instruction.
SM390
Access execution
flag
ON indicates completion
of intelligent function
module access
• This relay stores the status information on
the intelligent function module access
instruction that was just executed. (This
data is overwritten if the intelligent function
module access instruction is executed
again.)
• Used by the user in a program as a
completion bit.
Qn(H)
QnPH
QnPRH
Number Name
Meaning
Explanation
Set by
(When Set)
Corres-
ponding
ACPU
M9
Corresponding
CPU
