Appendix3 SPECIAL RELAY LIST
*1 This applies to the CPU of function version B or later.
*2 The module whose first 5 digits of serial No. is "09012" or later.
*3 The module whose first 5 digits of serial No. is "04122" or later.
*4 The module whose first 5 digits of serial No. is "07032" or later.
*5 The Universal model QCPU except the Q00UJCPU, Q00UCPU, Q01UCPU, and Q02UCPU.
*6 The relevant modules are as follows:
• The Universal model QCPU whose serial number (first five digits) is "10012" or later.
• Q13UDHCPU, Q26UDHCPU
*7 The Universal model QCPU except the Q00UJCPU.
SM391
GINT instruction
execution
completion flag
OFF : Not executed
ON : Execution
completed
Stores the execution status of the S(P).GINT
instruction.
• Turns off before execution of the
instruction.
• Turns on after completion of the instruction.
S (Instruction
execution)
New QnU
Number Name
Meaning
Explanation
Set by
(When Set)
Corres-
ponding
ACPU
M9
Corresponding
CPU
