Mitsubishi MELSEC Q Series Programming Manual

4-3
4
4) Indicates ladder mode expressions and execution conditions for instructions.
5) Indicates the data set for each instruction and the data type.
Execution Condition
Non-conditional
Execution
Executed while ON
Executed One Time
at ON
Executed while OFF
Executed One
Time at OFF
Code recorded on
description page
No symbol
recorded
Data Type Meaning
Bit Bit data or head number in bit data
BIN 16 bits BIN 16-bit data or head number in word device
BIN 32 bits BIN 32-bit data or head number in double word device
BCD 4-digit 4-digit BCD data
BCD 8-digit 8-digit BCD data
Real number Floating decimal point data
character string Character string data
Device name Device name data
