7-416
SP.FWRITE
*2: Indicates the range applicable only for the Universal model QCPU and LCPU.
Setting
Data
Meaning Setting Range Set by Data Type
+6
No. of
columns
designation
When binary write is specified at , always
set 0.
When CSV format write is specified at ,
set the number of columns where data will be
written.
0 : No columns. Regarded as
one row.
Other than 0 : Set to the specified number of
columns.
0H to
FFFF
H
(0 to 65535)
User
BIN 16 bits
+7
Data type
specification
0: Word
1: Byte
0,1 User
Head number of the devices storing a file name. A file name is expressed as follows:
Device Item Contents/Setting Data Setting Range Set by
to
+
File name
character
string
Designate the character string of a file name.
• When omitting an extension, also omit
the "." (Period).
• Limit the file name within 8 characters +
period + 3 characters.
• When 9 or more characters are used,
the extension is ignored regardless of its
presence, and "BIN" or "CSV" is
automatically assigned as an extension.
Character
string
User
Head number of the devices storing the data. Written data is expressed as follows:
Device Item Contents/Setting Data Setting Range Set by
No. of
request
write data
Designate the number of data to request
writing (word units).
This data should be designated in units of
words even when byte is designated by
+7.
1 to 480
1 to 32767
*2
User
+1 to
+
Write data
Data to request writing.
0000H to
FFFF
H
Bit device that turned ON at the completion of the processing.
( +1 is also turned ON at error completion.)
Bit
Device Item Contents/Setting Data Setting Range Set by
Completion
signal
Indicates the completion of the processing.
ON: Completed OFF: Not completed
––
System
+1
Error
completion
signal
Indicates whether the processing is normally
completed or abnormally completed.
ON: Error completion
OFF: Normal completion
––
D0
D0
D0
D0
D0
S1
S1
S1
S2
S2
D0
S2
S2
D1
D1
D1
D1
To Next Page
