Mitsubishi MELSEC Q Series Programming Manual

12-44
3003
[PARAMETER ERROR]
The number of device points set in the Device tab
of the PLC Parameter dialog box is outside the
range of the specifications of the CPU module.
■Collateral information
• Common information: File name/Drive name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN/At writing to
programmable controller
• Read the individual information of the error
using the programming tool to identify the
numeric value (parameter No.). Check the
parameters corresponding to the value, and
correct them as necessary.
• If the error still occurs after correcting the
parameter settings, the cause is a failure of the
program memory of the CPU module or
memory card. (Please consult your local
Mitsubishi representative, explaining a detailed
description of the problem.)
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
QCPU
LCPU
3004
[PARAMETER ERROR]
The parameter file is incorrect.
Alternatively, the contents of the file are not
parameters.
■Collateral information
• Common information: File name/Drive name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN/At writing to
programmable controller
Ensure that the parameter file version is ***.QPA
and the file contents are parameters.
3005
[PARAMETER ERROR]
The contents of the parameter are broken.
■Collateral information
• Common information: File name/Drive name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
• Read the individual information of the error
using the programming tool to identify the
numeric value (parameter No.). Check the
parameters corresponding to the value, and
correct them as necessary.
• Write the modified parameter items to the CPU
module again, and power-on the programmable
controller or reset the CPU module.
• If the same error occurred, the cause is a
hardware failure. (Please consult your local
Mitsubishi representative, explaining a detailed
description of the problem.)
Qn(H)
*15
QnPH
*17
QnPRH
*17
3006
[PARAMETER ERROR]
• The high speed interrupt is set in a Q02CPU.
• The high speed interrupt is set in a multiple CPU
system.
• The high speed interrupt is set when
aQA1S6B or QA6B is used.
• No module is installed at the I/O address
designated by the high speed interrupt.
■Collateral information
• Common information: File name/Drive name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN/At writing to
programmable controller
• Delete the setting of the Q02CPU' s high speed
interrupt.
To use high speed interrupts, change the CPU
module to one of the Q02H/Q06H/Q12H/
Q25HCPU.
• To use a multiple CPU system, delete the
setting of the high-speed interrupt.
To use high speed interrupts, change the
system to a single CPU system.
• To use either the QA1S6B or QA6B, delete
the setting of the high speed interrupt.
• To use high speed interrupts, do not use the
QA1S6B/QA6B.
• Re-examine the I/O address designated by the
high speed interrupt setting.
Qn(H)
*16
3007
[PARAMETER ERROR]
The parameter file in the drive specified as valid
parameter drive by the DIP switches is
inapplicable for the CPU module.
■Collateral information
• Common information: File name/Drive name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN/At writing to
programmable controller
Create parameters using the programming tool
and write them to the drive specified as a
parameter-valid drive by the DIP switches.
QnPRH
3009
[PARAMETER ERROR]
In a multiple CPU system, the modules for AnS, A,
Q2AS and QnA have been set to multiple control
CPUs.
■Collateral information
• Common information: File name/Drive name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN/At writing to
programmable controller
Re-set the parameter I/O assignment to control
them under one CPU module. (Change the
parameters of all CPUs in the multiple CPU
system.)
Qn(H)
*8
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
