Mitsubishi MELSEC Q Series Programming Manual

12-54
3107
[LINK PARA. ERROR]
• The CC-Link parameter setting is incorrect.
• The set mode is not allowed for the version of
the mounted CC-Link module.
■Collateral information
• Common information: File name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
Check the parameter setting.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
QCPU
LCPU
3200
[SFC PARA. ERROR]
The parameter setting is illegal.
• The block 0 does not exist although "Autostart
Block 0" was selected in the SFC tab in the PLC
Parameter dialog box.
■Collateral information
• Common information: File name
• Individual information: Parameter number
■Diagnostic Timing
•STOP→RUN
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
Q00J/Q00/Q01
*8
QnPH
QnPRH
QnU
LCPU
3201
[SFC PARA. ERROR]
The block parameter setting is illegal.
■Collateral information
• Common information: File name
• Individual information: Parameter number
■Diagnostic Timing
•STOP→RUN
Qn(H)
QnPH
QnPRH
3202
[SFC PARA. ERROR]
The number of step relays specified in the device
setting of the PLC parameter dialog box is less
than that used in the program.
■Collateral information
• Common information: File name
• Individual information: Parameter number
■Diagnostic Timing
•STOP→RUN
3203
[SFC PARA. ERROR]
For the execution type of the SFC program, other
than "Scan" is selected in the Program tab of the
PLC Parameter dialog box.
■Collateral information
• Common information: File name
• Individual information: Parameter number
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
*5
Qn(H)
QnPH
QnPRH
QnU
LCPU
3300
[SP. PARA ERROR]
The start I/O number in the intelligent function
module parameter set on GX Configurator differs
from the actual I/O number.
■Collateral information
• Common information: File name
• Individual information: Parameter number
*4
■Diagnostic Timing
• At power-on/At reset/STOP→RUN/At writing to
programmable controller
Check the parameter setting.
QCPU
LCPU
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
