12-60
4100
[OPERATION ERROR]
The instruction cannot process the contained data.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*1
QCPU
LCPU
[OPERATION ERROR]
An error occurred on the SP.FREAD or
SP.FWRITE instruction during accessing the ATA
or SD memory card.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
• Take measurements against noise.
• Reset and restart the CPU module. If the same
error code is displayed again, the cause is a
hardware failure of the ATA card or SD memory
card. (Please consult your local Mitsubishi
representative, explaining a detailed
description of the problem.)
Qn(H)
QnPH
QnPRH
QnU
*19
LCPU
[OPERATION ERROR]
The file being accessed by other functions with
SP.FWRITE instruction was accessed.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
• Stop the file accessed with other functions to
execute SP.FWRITE instruction.
• Stop the access with other functions and the
SP.FWRITE instruction to execute at same
time.
QnU
*19
LCPU
4101
[OPERATION ERROR]
• The number of setting data dealt with the
instruction exceeds the applicable range.
• The storage data and constant of the device
specified by the instruction exceeds the
applicable range.
• When writing to the host CPU shared memory,
the write prohibited area is specified for the write
destination address.
• The range of storage data of the device
specified by the instruction is duplicated.
• The device specified by the instruction exceeds
the range of the number of device points.
• The interrupt pointer No. specified by the
instruction exceeds the applicable range.
• A link direct device, intelligent function module
device, and cyclic transmission area device are
specified for both (S) and (D) with the BMOV
instruction.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
QCPU
LCPU
[OPERATION ERROR]
• The storage data of file register specified by the
instruction exceeds the applicable range. Or, file
register is not set.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
QnU
*18
LCPU
Error
Code
(SD0)
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
