Mitsubishi MELSEC Q Series Programming Manual

12-61
1
2
3
12
6
6
7
8
12.1 Error Code List 12.1.6 Error code list (4000 to 4999)
4101
[OPERATION ERROR]
• The block data that crosses over the boundary
between the internal user device and the
extended data register (D) or extended link
register is specified (including 32-bit binary, real
number (single precision, double precision),
indirect address, and control data).
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*1
QnU
LCPU
4102
[OPERATION ERROR]
In a multiple CPU system, the link direct device
(J\) was specified for the network module
under control of another station.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
• Delete from the program the link direct device
which specifies the network module under
control of another CPU.
• Using the link direct device, specify the network
module controlled by the own station.
Q00/Q01
*8
Qn(H)
*8
QnPH
QnU
*18
4102
[OPERATION ERROR]
• The network No. or station No. specified for the
dedicated instruction is wrong.
• The link direct device (J\) setting is incorrect.
• The module No./network No./number of
character strings exceeds the range that can be
specified.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*1
QCPU
[OPERATION ERROR]
• The module number specified with a dedicated
instruction is incorrect.
• The module number, network number, or the
number of character strings specified with a
dedicated instruction exceeded the allowable
range.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
LCPU
[OPERATION ERROR]
The character string (" ") specified by a dedicated
instruction cannot be used for the character string.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
QnU
LCPU
4103
[OPERATION ERROR]
The configuration of the PID dedicated instruction
is incorrect.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Q00J/Q00/Q01
*8
Qn(H)
QnPRH
QnU
LCPU
4105
[OPERATION ERROR]
PLOADP/PUNLOADP/PSWAPP instructions were
executed while setting program memory check.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
• Delete the setting for the program memory
check.
• When using the program memory check, delete
PLOADP/PUNLOADP/PSWAPP instructions.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/Continue
QnPH
*12
Error
Code
(SD0)
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
