Mitsubishi MELSEC Q Series Programming Manual

12-62
4107
[OPERATION ERROR]
33 or more multiple CPU dedicated instructions
were executed from one CPU module.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Using the multiple CPU dedicated instruction
completion bit, provide interlocks to prevent one
CPU module from executing 33 or more multiple
CPU dedicated instructions.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*1
Q00/Q01
*8
Qn(H)
*8
QnPH
Q00UCPU
Q01UCPU
Q02UCPU
4109
[OPERATION ERROR]
With high speed interrupt setting PR, PRC,
UDCNT1, UDCNT2, PLSY or PWM instruction is
executed.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Delete the high-speed interrupt setting.
When using high-speed interrupt, delete the PR,
PRC, UDCNT1, UDCNT2, PLSY and PWM
instructions.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*1
Qn(H)
*21
4111
[OPERATION ERROR]
An attempt was made to perform write/read to/from
the CPU shared memory write/read disable area of
the own station CPU module with the instruction.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*1
Q00/Q01
*8
QnU
4112
[OPERATION ERROR]
The CPU module that cannot be specified with the
multiple CPU dedicated instruction was specified.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Q00/Q01
*8
QnU
*18
4113
[OPERATION ERROR]
• When the SP.DEVST instruction is executed, the
number of writing to the standard ROM of the
day exceeds the value specified by SD695.
• The value outside the specified range is set to
SD695.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
• Check that the number of execution of the
SP.DEVST instruction is proper.
• Execute the SP.DEVST instruction again on or
after the following day. Or change the value in
SD695.
• Correct the value of SD695 so that it does not
exceed the range.
RRUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/Continue
QnU
LCPU
4116
[OPERATION ERROR]
A built-in I/O instruction that is disabled with a
parameter was executed.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
• Enable the built-in I/O function with parameters.
• Prohibit executions of a built-in I/O instruction
that is disabled with a parameter.
LCPU
Error
Code
(SD0)
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
