Mitsubishi MELSEC Q Series Programming Manual

12-66
4231
[INST. FORMAT ERR.]
The number of IX and IXEND instructions is not
equal.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
QCPU
4235
[INST. FORMAT ERR.]
The configuration of the check conditions for the
CHK instruction is incorrect.
Alternatively, a CHK instruction has been used in a
low speed execution type program.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Qn(H)
QnPH
4350
[MULTI-COM. ERROR]
• The multiple CPU high-speed transmission
dedicated instruction used in the program
specifies the wrong CPU module. Or, the setting
in the CPU module is incompatible with the
multiple CPU high-speed transmission
dedicated instruction.
• The reserved CPU is specified.
• The uninstalled CPU is specified.
• The head I/O number of the target CPU/16 (n1)
is outside the range of 3E0H to 3E3H.
• The CPU module where the instruction cannot
be executed is specified.
• The instruction is executed in a single CPU
system.
• The host CPU is specified.
• The instruction is executed without setting the
"Use multiple CPU high speed communication".
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Read common information of the error using the
programming tool to identify the numeric value
(program error location). Check the error step
corresponding to the value, and correct it as
necessary.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
QnU
*20
4351
[MULTI-COM. ERROR]
• The multiple CPU high-speed transmission
dedicated instruction specified by the program
cannot be executed to the specified target CPU
module.
• The instruction name is wrong.
• The instruction unsupported by the target CPU
module is specified.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
4352
[MULTI-COM. ERROR]
The number of devices for the multiple CPU high-
speed transmission dedicated instruction specified
by the program is wrong.
■Collateral information
• Common information: Program error location
• Individual information:-
■Diagnostic Timing
• When instruction executed
Error
Code
(SD0)
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
