Mitsubishi MELSEC Q Series Programming Manual

12-78
6106
[TRK. TRANS. ERR.]
• A timeout error occurred in tracking (data
transmission).
(This error may be caused by tracking cable
removal or other system power-off (including
reset).)
• The error occurred at a startup since the
redundant system startup procedure was not
followed.
(This can be detected from the control system or
standby system of the redundant system.)
■Collateral information
• Common information: Tracking transmission
data classification
• Individual information:-
■Diagnostic Timing
• Always
• Check the CPU module or tracking cable. If the
error still occurs, this indicates the CPU module
or tracking cable is faulty. (Please consult your
local Mitsubishi representative, explaining a
detailed description of the problem.)
• Confirm the redundant system startup
procedure, and execute a startup again.
RUN:
On
ERR.:
On
CPU Status:
Continue
QnPRH
6107
[TRK. TRANS. ERR.]
A data sum value error occurred in tracking (data
reception).
(This can be detected from the control system or
standby system of the redundant system.)
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• Always
6108
[TRK. TRANS. ERR.]
• A data error (other than sum value error)
occurred in tracking (data reception).
(This error may be caused by tracking cable
removal or other system power-off (including
reset).)
• The error occurred at a startup since the
redundant system startup procedure was not
followed.
(This can be detected from the control system or
standby system of the redundant system.)
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• Always
• Check the CPU module or tracking cable. If the
error still occurs, this indicates the CPU module
or tracking cable is faulty. (Please consult your
local Mitsubishi representative, explaining a
detailed description of the problem.)
• Confirm the redundant system startup
procedure, and execute a startup again.
6110
[TRK. SIZE ERROR]
The tracking capacity exceeded the allowed range.
(This can be detected from the control system or
standby system of the redundant system.)
■Collateral information
• Common information: Reason(s) for tracking
size excess error
• Individual information:-
■Diagnostic Timing
• When an END instruction executed
Reexamine the tracking capacity.
6111
[TRK. SIZE ERROR]
The control system does not have enough file
register capacity for the file registers specified in
the tracking settings.
(This can be detected from the control system or
standby system of the redundant system.)
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• When an END instruction executed
Switch to the file registers of which capacity is
greater than the file registers specified in the
tracking settings.
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
