Mitsubishi Outlander PHEV 2019

No.
Sym-
bol
Electrical sys-
tem
Ca-
paci-
ties
6 Rear fog lamp
10 A
*2
7
Accessory sock-
et
15 A
8
Rear window
wiper
15 A
9 Sunroof 20 A
10 Ignition switch 10 A
11 Option 10 A
12
Hazard warning
flasher
15 A
13
4-wheel drive
system
10 A
14
Stop lamps
(Brake lamps)
15 A
15 Instruments 10 A
16 SRS airbag 7.5 A
17 Radio 15 A
*1
: Fusible link
*2
: Even if your vehicle is equipped with the
rear fog lamp, the fuse of the rear fog lamp
may not be installed on your vehicle.
No.
Sym-
bol
Electrical sys-
tem
Ca-
paci-
ties
18
Control unit re-
lay
7.5 A
19
Interior lamps
(Room lamps)
15 A
20
Reversing lamps
(Backup lamps)
7.5 A
21
Heated door
mirror
7.5 A
22
Outside rear-
view mirrors
10 A
23
Cigarette lighter/
Accessory sock-
et
15 A
24
Charge 7.5 A
Heated steering
wheel
15 A
25
Power seat
(Driver seat)
30 A
*1
26 Heated seat 30 A
*1
: Fusible link
*2
: Even if your vehicle is equipped with the
rear fog lamp, the fuse of the rear fog lamp
may not be installed on your vehicle.
No.
Sym-
bol
Electrical sys-
tem
Ca-
paci-
ties
27
Power seat (Pas-
senger seat)
30 A
*1
*1
: Fusible link
*2
: Even if your vehicle is equipped with the
rear fog lamp, the fuse of the rear fog lamp
may not be installed on your vehicle.
l
Some fuses may not be installed on your
vehicle, depending on the vehicle model
or specifications.
l
The table above shows the main equip-
ment corresponding to each fuse.
Fuses
11-20
OGGE19E1
Maintenance
11
