points indicated by arrows and pry gen-
tly to remove the cover (A).
2. Remove the 3 screws (B) and remove
the lamp unit.
NOTE
l
When unfastening the screws of the fog
lamp, be careful not to mistakenly move the
beam position adjustment screw (C).
3. While holding down the tab (D), pull out
the socket (E).
4. Turn the bulb (F) anticlockwise to re-
move it.
5. To install the bulb, perform the removal
steps in reverse.
Replacement of lamp bulbs
11-29
OGGE19E1
Maintenance
