Rear fog lamp (driver’s side)/
Reversing lamp (Passenger’s
side)
E01004101655
1. Insert a straight blade (or minus) screw-
driver with a cloth over its tip at the edge
of the lamp unit, and then push the lamp
unit upward to remove it.
2. Turn the socket (A) anticlockwise to re-
move it, and then pull the bulb out of the
socket.
3. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lamp unit, first insert the
notch (B) into the hole on the body, and then
push on the lamp unit to fit it into place.
Rear combination lamps
E01004202767
1. Open the tailgate.
Replacement of lamp bulbs
11-30
OGGE19E1
Maintenance
11
