2. Remove the screws (A), and then move
the lamp unit towards the rear of the ve-
hicle to unfix the notch (B) and pins (C)
of the lamp unit.
3. Turn the socket anticlockwise and re-
move it, and then pull the bulb out of the
socket.
D- Rear turn-signal lamp
E- Tail lamp and stop lamp (LED)-cannot
be replaced
NOTE
l
The tail lamp and stop lamp use an LED in-
stead of the bulb.
If you need to repair or replace these lamps,
contact a MITSUBISHI MOTORS Author-
ized Service Point.
4. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lamp unit, align the
notch (F) and pin (G) on the lamp unit with
the clip (H) and hole (I) in the body.
Licence plate lamps
E01004602325
1. Remove while pressing the lamp unit
(A) to the left side of the vehicle.
2. Insert a minus screwdriver with the end
covered with a cloth or other object to
press the hook (B) aside and remove the
lens.
Replacement of lamp bulbs
11-31
OGGE19E1
Maintenance
