－12－
Please make sure to pull the upper thread out of the needle before winding the bobbin
5-3. Threading the upper thread
Please thread the upper thread with referring to the below figures.
5-4. Winding the bobbin thread
(1) Turn the power switch ON.
(2) Press the key on the operation panel
to enter the second operation window.
(3) Pass through the thread from the thread
stand (NO.1) as shown on the below figure
then, wind the thread to the empty bobbin
(NO.2) in the arrow mark “a” direction
couple times and insert the bobbin (NO.3)
into the bobbin winder (NO.4).
(4) Push the adjust lever (NO.6) in the arrow
mark “b” direction.
(5) Step on the black color foot switch (NO.5)
then work holder goes down.
(6) Press the key, then work holder
moves to home position.
★Please make sure to turn the power switch OFF before threading the upper thread.
Caution
To Next Page
