－1－
1. STRUCTURE OF THE SEWING MACHINE
PLK-E0504 electronic bar tack machine is constructed with the following main parts.
9
6
4
3
2
1
5
7
8
Work holder foot switch
Machine head
Half switch
Table top
Thread Stand
Operation panel
Servo-motor
Steel stand
Control
box
Start foot switch
Work holder
pedal
