4 - 34 4 - 34
MELSEC-Q
4 WHEN THE QCPU ACCESSES THE OTHER STATION PLC USING THE
DATA LINK INSTRUCTION
(2) Instruction execution timing
(a) When normal completion
Channel 1
0 END
Sequence scan
0END0 END 0 END 0 END
Execution instruction
REQ
1 scan
0 END
Sequence scan
0 0 END0 END
OFF
Execution completion
device (device
specified with (D2))
Local station
QCPU
Execution completion
device ((D2)+1 device)
Ethernet
module
Ethernet
module
Target station
Q/QnACPU
00 END 00 END
Clock data read/write
Remote RUN/STOP
