2 - 31 2 - 31
MELSEC-Q
2 USING THE E-MAIL FUNCTION
(4) Receiving by the a personal computer
The following explains how a PC/UNIX/portable terminal receives e-mail sent
from the Ethernet module.
After setting an environment for using the Internet with application software that
processes e-mails, e-mails can be received on a receive message screen as
shown below.
(Example) The following shows an example of the reception of e-mail sent using
the MSEND instruction (see (3)).
(The screen display shows is that of Microsoft
®
Corporation’s
Outlook Express 5.)
Mail address of Ethernet module
••• (b)
••• (c)
Mail address of external device
••• (a)
(a) From
Displays the e-mail address of the Ethernet module.
REMARK
By entering the mail addresses of the send destination devices in the address book,
the registered names (display names) can be displayed and it makes the
management easier.
(b) Subject
This indicates the transmission destination No. (
1) and the Subject written
by a sequence program.
1 The Ethernet module automatically adds this number sequentially,
starting from 1.
(After the maximum number (4294967296) is reached, the number
starts again from 0.)
(c) Main text of e-mail
This indicates the main text of e-mail sent by the Ethernet module.
To Next Page
