4 - 11 4 - 11
MELSEC-Q
4 WHEN THE QCPU ACCESSES THE OTHER STATION PLC USING THE
DATA LINK INSTRUCTION
(b) RECV instruction (for receive by the main program)
[Network number designation]
JP.RECV
JP: Exection
during startup
Jn
Receive command
(S)
(D1) (D2)
[Network module/Ethernet module start I/O signal designation]
GP.RECV
GP: Execution
during startup
Un
Receive command
(S) (D1) (D2)
Setting details Setting range
Jn Local station network number
1 to 239 : Network number
254 : Network designated in the
valid module for other
station access
Un
Start I/O signal of the local station network module/ Ethernet
module
Designate by higher two digits when the I/O signal is
expressed by three digits
0 to FE
H
(S)
Control data storage head device
Designate the head device of the local station that stores
the control data.
Word device
2
(D1)
Receive data storage head device
Designate the head device of the local station that stores
the receive data.
Word device
2
Receive completion device
Designate the device to turn on one scan when the
receive is complete.
(D2)
................
OFF: Incomplete ON: Complete
(D2)
(D2) + 1
..........
OFF: Normal ON: Error
Bit device
1
Word device bit designation
3
1: Bit device
..................................
X, Y, M, L, F, V, B
2: Word device
...............................
T, C, D, W, ST, R, ZR
3: Word device bit designation
......
Word device
.
Bit number
