MKN FlexiCombi MagicPilot FKECOD615 - Page 15

Description of the unit
15Installation instructions
Model: FKECOD
Size 615 621 115 121 215 221
Temperature resistance (°C) 95
Maximum flow rate (l/min) 10
Exhaust air connection
Connection to unit (mm) 53 73
Maximum length (m) 2,5
Temperature resistance (°C) 180
Transformer voltage
Type of connection 3NPE / AC 50/60Hz
Voltage range (V) 200 — 240
Transformer T1
Marking or colour of the cores Blue Red
Voltage measured (V) Voltage at the transformer (V)
190 — 200 0 200
201 — 220 0 220
221 — 230 0 230
231 — 240 0 240
241 — 250 0 250
Type of connection 3NPE / AC 50/60Hz
Voltage range (V) 380 — 415
Transformer T1
Marking or colour of the cores Blue Red
Voltage measured (V) Voltage at the transformer (V)
370 — 380 0 220
381 — 400 0 230
401 — 420 0 240
Type of connection 3PE / AC 50/60Hz
Voltage range (V) 380 — 480
Transformer T0 T1
Marking or colour of the cores T0 - 0V T0 - 230V T0 - 400V Blue Red
Voltage measured (V) Voltage at the transformer (V)
370 — 380 0 219 400 0 230
381 — 415 0 230 400 0 230
416 — 450 0 230 440 0 230
451 — 490 0 230 480 0 230
10013865-0AIBE-B
