MKS e-Vision+ - Exploded View of the Analyser

e-Vision and e-Vision+ LP101013.100 – 01 January 2004
MKS Instruments, Spectra Products
34
8.2 Exploded view of the Analyser
Item Description (Dimensions in mm) Part Number
1 Source Assembly Tungsten Fils 842-021
1 Source Assembly Thoria Fils 842-022
2+3 Screw M2 x 4 200902004
1
2
3
