MKS e-Vision+ - Filament Plate

e-Vision and e-Vision+ LP101013.100 – 01 January 2004
MKS Instruments, Spectra Products
35
2
3
4
5
1
6
8.3 Filament Plate
Item Description
(Dimensions in
mm)
Part Number
1 Screw M1.6 x 3 (3 off) 200901603
2 Barrel Connector 305040214
3 Screw M2 x 4 200902004
4 Filament Plate Tungsten Fils LM508-015PL
4 Filament Plate Thoria Fils LM508-020PL
5 Filament Screen 305080594
6 Screw M1.6 x 4 (3 off) 200901604
