Page #6 background imageLoading...
Page #6 background image
MKS Instruments UK Ltd
Microvision2 Hardware Manual – SP101015.102 August 2010
6
1. Specifications
1.1 Mechanical
Microvision2
Dimensions:
127mm wide x 127mm x 179mm deep, plus 46mm over analyser connector to face of CF flange.
Weight:
1.7 kg
24VDC Power Supply
Dimensions:
75mm wide x 45mm high x 146mm deep plus 30mm over strain relief.
Weight:
0.6 kg
Analyser
Max. Operating pressure
7.6x10
-5
(1x10
-4
mbar)
